300PSI Fig No.: YS-300-FG
FEATURES & SPECIFICATIONS
- Fusion bonded epoxy coated RAL3002
- Flange drilled to ANSI B16.1 Class 125 / ANSI B16.5 Class 150 / EN1092-2 PN16 / BS10 Table D / Table E / AWWA C606
- Grooved ends to suit ANSI or BS standard pipe
- Working pressure : 300psi
- Working temperature : -10°C … 120°C
MATERIALS LIST
| name | material |
Body | Ductile Iron A536 65-45-12 |
Cover | Ductile Iron A536 65-45-12 |
Screen | Stainless Steel AISI 304 |
Gasket | EPDM |
Plug | Carbon Steel |
