365PSI Fig No.: 5201-365-GGP
FEATURES & SPECIFICATIONS
- Swing type
- Spring loaded EPDM sealed carbon steel clapper
- Fusion bonded epoxy coated RAL3002
- Grooved ends to suit ANSI / AWWA and BS Pipe size
- Working pressure : 365psi
- Working temperature : 0°C … 80°C
MATERIALS LIST
| name | material |
Body | Ductile Iron ASTM A536 65-45-12 |
Seat | Bronze ASTM B62 C83600 |
Clapper | Carbon Steel WCB Q235 + EPDM |
Clapper Arm | Stainless Steel AISI 304 |
Washer | Stainless Steel AISI 304 |
Hexagonal Slot Thin Nut | Stainless Steel AISI 304 |
Split Pin | Stainless Steel AISI 304 |
