300PSI Fig No.: 3299-LI-300-FG
- Rising stem, Outside Screw & Yoke (OS&Y)
- Stainless steel stem
- Valve conforms to AWWA C515 / BS5163
- Fusion bonded epoxy coated interior and exterior RAL3002
- Flange drilled to ANSI B16.1 Class 125 / ANSI B16.5 Class 150 /EN1092-2 PN16 / BS10 Table D / Table E
- Grooved ends to suit ANSI / AWWA and BS Pipe size
- Working pressure : 300psi
- Working temperature : -10°C … 120°C
MATERIALS LIST
| name | material |
Body | Ductile Iron ASTM A536 65-45-12 |
Wedge | Ductile Iron ASTM A536 65-45-12 + EPDM |
Wedge Nut | Stainless Steel AISI 304 |
Stem | Stainless Steel AISI 304/420 |
Bonnet | Ductile Iron ASTM A536 65-45-12 |
Gasket | EPDM |
Packing | Graphite |
Stem Nut | Bronze ASTM B62 |
Handwheel | Ductile Iron ASTM A536 65-45-12 |
