300PSI Fig No.: 5301-300W
FEATURES & SPECIFICATIONS
- Spring loaded double door
- Rubber seat for non-slam effect
- Fusion bonded epoxy coated RAL3002
- Valve conforms to API 594
- Wafer connection to ANSI Class 125 / ANSI Class 150 / EN 1092-2 PN16 / BS10 Table D / Table E
- Working pressure : 300psi
- Working temperature : -20°C … 110°C
MATERIALS LIST
| name | material |
Body | Ductile Iron A536 65-45-12 |
| Disc | Stainless Steel A351 CF8 |
Stem | Stainless Steel AISI 416 |
Seat-Ring | EPDM |
Spring | Stainless Steel AISI 304 |
Note : Lifting ring for DN200 and above
