300PSI Fig No.: FPB-300G
FEATURES & SPECIFICATIONS
- Valve conforms to MSS SP-67 / BS EN593: 2009
- Fusion bonded epoxy coated interior and exterior RAL3000
- Factory installed UL listed double tamper switches
- Valve approved for indoor and outdoor use
- Grooved ends to suit BS or ANSI pipe size
- Working pressure : 300psi – Non Shock Coldwater Max. Test Pressure : 600psi / FM Standard 1112
- Working temperature : -20°C … 110°C
MATERIALS LIST
| name | material |
Signal Gearbox | Ductile Iron ASTM A536 65-45-12 |
Lower Shaft Sealing Nut | WCB ASTM A216 |
Lower Shaft | Stainless Steel SS416 |
Disc | DI+EPDM |
Upper Shaft | Stainless Steel SS416 |
Body | Ductile Iron ASTM A536 65-45-12 |
Shaft Seal | EPDM |
Upper Shaft Sealing Nut | WCB ASTM A216 |
