300PSI Fig No.: BBT-300
FEATURES & SPECIFICATIONS
- Factory installed UL listed double tamper switches
- Valve approved for indoor and outdoor use
- Threaded : NPT or BSPT
- Working pressure : 300psi Max. Test Pressure : 600psi
- Max. working temperature : 250°F (120°C)
MATERIALS LIST
| name | material |
Body | Bronze C836000 |
Disc | Stainless Steel AISI304 |
Handwheel | WCB |
Seat | Viton |
Indicator | Powder Metal |
Housing | Forged Brass |
