300PSI Fig No.: 9702
FEATURES & SPECIFICATIONS
- Threaded ends : NPT or BSPT
- Working pressure : 200psi
- Working temperature : -10°C … 120°C
MATERIALS LIST
| name | material |
Body | Ductile Iron A536 65-45-12 |
Cover | Ductile Iron A536 65-45-12 |
Level | Stainless Steel AISI 304 |
Seat Ring | Stainless Steel |
Float | Stainless Steel AISI 304 |
Float Arm | Stainless Steel AISI 304 |
Orifice Button | Viton |
